1.4
Description
Set of:
4 Resistance Boxes:
Model BR04: 4 decades - 1Ω to 11.11kΩ
Model BR05: 5 decades - 1Ω to 111.11kΩ
Model BR06: 6 decades - 1Ω to 1.11111MΩ
Model BR07: 7 decades - 1Ω to 11.11111MΩ
covering all the resistance values from 1Ω to 11.11111MΩ
1 Capacitance Box:
Model BC05: 5 decades - 0.1nF to 11.111µF
covering all the capacitance values from 0 to 11.111µF
These decade boxes are built into a metal bench-top box. They are used for test-
ing and calibration.
The main function of these decade boxes is to create a resistance, capacitance
or inductance with a specific value by using a combination of the rotary decade
switches.
They are equipped with Ø 4mm safety terminals for connection.
For safe use, they comply with standard EN 61010-1 (2001).
1.5
Operation
The ground (earth) terminal must be connected to a protective ground (earth)
before taking any measurements.
Do not inject any voltage measurements greater than 150V to ground (earth) and
comply with the maximum acceptable current for each decade switch.
Decade Box Models BR04 / BR05 / BR06 / BR07 / BC05
3
