- Whenever you leave the lawn mower;
come to a complete stop and, where a key is fitted remove the key:
- Before refuelling;
Reduce the throttle setting during engine shut down and, if the engine is provided with a shut-off valve, turn
the fuel off at the conclusion of mowing;

Go slow when using a trailing seat;

Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition;
Never store the equipment with petrol in the tank inside a building where fumes can reach an open flame

or spark;

Allow the engine to cool before storing in any enclosure;
To reduce the fire hazard, keep the engine, silencer, exhaust, battery compartment and petrol storage area

free of grass, leaves, or excessive grease;

Check the grass catcher frequently for wear or deterioration;
Replace worn or damaged parts for safety; Only use original spare parts

Blade sharpening and balancing including relative dismantling and re-assembly are complicated operations

which involves specific competence as well as special equipment. For safety reasons, these operations

must be carried out by a specialized technical assistance centre. The same procedure applies for blade
replacement.
The cutting edges of the mower blade are sharp and can lacerate (cut) skin tissue. Care should be taken
when doing any repair work on or around the mower blade.

If the fuel tank must be drained, this should be done outdoors.

Drive
Factory model
Engine
Nominal Power
Max operation Engine
Speed
Displacement
Height Adjustments
Cutting Heights
Grass collector
Grass collector volume

Cutting width

Self-propelled
TZ46SB-139
TZ1P65F
2.0kW
2800min-1
139 cm
3
Central adjustments
25-70mm (7 stages)
Rear bag
50 litres
46 cm

MAINTENANCE AND STORAGE

PRODUCT SPECIFICATIONS

Self-propelled
TZ51SF-BS625EXi
Central adjustment
25-70mm (7 stages)
BS625Exi
2.2kW
2800min-1
150 cm
3
3in1
50 litres
51 cm
6
