The tool has been designed and constructed to reduce
noise to minimum levels. (See technical data 2.1).
In particular working conditions the maximum sound
level at the place of work may exceed 85 dBA. In this
case the operator must use ear protectors.
Work carefully and maintain the tool in perfect working
order, for your own safety.
2.4.1 SWITCH
In order to prevent accidental starting the machine is
equipped with a safety device. Therefore the black button
H (fig.1), positioned beside the handgrip, must be pressed
first and then the start button.
2.4.2 GUARD
In order to protect the roller from accidental contact with
the operator, it has been protected with a fixed safety
guard (on the belt side) and a movable guard, that will
allow blade changing operations to be performed, if
necessary. In this manner access cannot be gained to
the roller (or the blades) during use.
2.4.3 CUTTING DEPTH
The cutting depth can be regulated without having to
overturn the machine, by means of the special knob.
2.4.4 GUIDES
During working operations it is advised to use the parallel
guide and graduated support, or to fit the planer on the
stationary support.
This will produce better quality work and guarantee major
safety for the user.
2.4.5 HANDGRIPS
The planer is equipped with an ergonomic handgrip and a
knob, which allows the cutting depth to be regulated.
Attention
Both of the operator's hands must be firmly kept on the
handgrips during working operations.
3 GENERAL SAFETY STANDARD
See attached information: General safety standards.
This booklet forms an integrative part of this manual.
4

INSTALLATION

4.1 PACKAGING
This tool is sold complete with accessories and the
user's manual, contained in a cardboard box of suitable
size and thickness for the work that the tool is intended
for. This container should be kept as it will prove useful
for your work.
4.2 INSTALLATION
The environmental conditions, temperature, humidity,
lighting, the correct dislocation of your tool and the
cleanliness of the place of work are important conditions
for personal safety and tool performance. These factors
All manuals and user guides at all-guides.com
should always be kept under control in order to improve
working conditions and ensure safety.
4.3
Before connecting the tool to the mains make sure that it
complies with the standard regulations of the country in
question, and that the voltage and frequency correspond
to the details on the data plate.
When using extension leads, make sure that cable cross-
section conforms to the length of the lead. When using a
wind-up extension make sure that is completely unwound
so as to avoid overheating.
4.4
The tool that you have purchased is a portable electric
power tool.
Only one user should operate this tool, given its shape,
weight and maneuverability.
Normal use requires that both of the operator's hands are
firmly kept on the two handgrips.
The tool is already regulated according to standard
parameters by the constructor when supplied.
If necessary the cutting depth can be adjusted.
5.1
Once the planing depth has been determined, rotate the
rotating knob E (fig.1) until the selected value is indicated.
The cutting depth can be regulated from 0 to 3 mm.
5.2
If during use, or after having replaced components,
the cutting flatness needs to be regulated, proceed as
described in point 8.4.
6.1
The CMT3 planer is a particularly sturdy and resistant
machine; extremely versatile and maneuverable, ideal for
all continuous wood planing work.
Guide the planer with both hands firmly on the
handgrips.
During use, make sure that the power supply cable does
not impede working operations or come into contact with
the tool.
Small work pieces should be securely clamped in order
that they remain in position during planing operations (for
example: fix in position with a clamp).
6.2
The machine is supplied ready for use, requiring only the
planing depth to be determined:
- If planing operations need to be carried out at a preset
6
ELECTRICAL CONNECTION
PLACE OF WORK
5

REGULATION

CUTTING DEPTH REGULATION
REGULATION OF THE CUTTING FLATNESS
6

OPERATION AND USE

SAFETY
ATTENTION:
Wait until the tool has completely stopped before putting
it down.
STARTING THE MACHINE
