Control panel

For information about combinations of lights that flash/are on, see
"Troubleshooting".
1
2
3
4
5
Figure 2. Control panel
Pos Light/button
1 on/off
2 filter I
3 filter II
4 stop
5 calibration
6 purification level I
7 purification level II
8 purification level III

Pro inside and replacement components

Pos Description
1 Base plate
2 Prefilter I, Pro 600: Carbon Block
Prefilter I, Pro 400: Sediment filter
3 Prefilter II, Pro 600: Carbon Block
Prefilter II, Pro 400: Carbon filter,
granulated
4 Reverse osmosis membrane
Membrane service kit, type HR
(High Rejection)
Membrane service kit, type HF
(High Flow)
All manuals and user guides at all-guides.com
6 7
Description
On: The water purifier is connected to power.
Off: The water purifier is not connected to power.
Flashes: The water purifier flushes. Flushing cannot be stopped.
On: The filter must be replaced. Pro 600: Replace both
Carbon Block filters.
On: The filter must be replaced. Pro 600: Replace both
Carbon Block filters.
Flashes/On: Something is wrong, see "Troubleshooting".
Calibration button, various functions see Complete
User manual.
On: Purification level I-III indicates clean water purification
level. Low level I to high level III.
Art.-Nr.
919240005
919240002
919240005
919240003
150718900-SP
150718901-SP
07
8
1
Figure 3. Pro inside
EN
2 3 4
