Locking & Limiting
Receiver Wiring (RF only)
RX1
ELECTRONICS
N L 1 2 3 4
Note: 1) For mains voltage operated systems, link terminal 2 to mains live supply
2) Power supply to unit must not be switched by timeswitch
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - info@mytub.co.uk
All manuals and user guides at all-guides.com
RX2 and RX3
A
COM ZONE ZONE
1 OFF
1 ON
ELECTRONICS
B C 1 2 3 4 5 6
N L
COM
ZONE ZONE
1 ON 1 OFF
GB
TERMINAL 6
RX3 ONLY
ZONE ZONE
2 ON 3 ON
7
