Special Features

EN
DE
• Strobe Rejection – The RE Plus is designed to reject and eliminate
FR
unwanted signals from strobe lights.
IT
• Beam Finding – Passing the RE Plus through the laser beam will
ES
cause the sensor to beep twice quickly.
PT
• Out of Beam Display – If the detector is moved out of the detector
NL
range, the arrow display will indicate the direction to move to return
DA
to the laser beam.
NO
• Laser Low Battery – Alerts the user when the laser's batteries are
SV
getting low.
FI
• Zero Accuracy Band – With power off, press and hold the accuracy
switch while turning on the detector. To exit, turn off the detector.
This feature is used when checking the accuracy of the laser

Care and Transport

Transport
When transporting the receiver always use the original carton or
the laser transmitter case.
Storage
Respect the temperature limits, -40° to +70°C
(-40° to +158°F), when storing the instrument.
If the detector will not be used for a month or more, it is recom-
mended to remove the batteries.
Cleaning
Do not wipe dust or dirt off the detector reception window or
display windows with a dry cloth or other abrasive material as
scratching could occur, reducing visibility through these windows.
A soft cloth and mild soap and water are effective. The unit may
be submerged under water or sprayed with a low pressure hose if
necessary. Do not use any fluids other than water, as they may
attack the polymer components.
4 Rod Eye Plus
