Securing the TAKATA MIDI I-SIZE in a
forward-facing position [I-SIZE_BASE_032]
Step 1 – Check the TAKATA I-SIZE BASE
WARNING!
The TAKATA MIDI I-SIZE must only be secured via
the TAKATA I-SIZE BASE. As such, ensure that the
7$.$7$ ,6,=( %$6( LV DWWDFKHG ¿UPO\ DQG
correctly to the vehicle seat. If you notice that the
TAKATA I-SIZE BASE can still be moved around,
repeat all the steps in Section 4 – Use in the vehicle
(Securing the TAKATA I-SIZE BASE).
WARNING!
[I-SIZE_BASE_024] Before installing the TAKATA
MIDI I-SIZE on the TAKATA I-SIZE BASE, check
that both rear connection hooks of the TAKATA
I-SIZE BASE are open. The connection hooks have
been correctly unlocked if you can see a red marking
on the top of each release element.
,Q FDVH RI XQFOHDU FRORXU RU LQ GLI¿FXOW OLJKW FRQGLWLRQV
push down one of the release elements on the exterior
of the connection arms to ensure that both connection
hooks are open.
Step 2 – Lock the seat into the TAKATA I-SIZE BASE
[I-SIZE_BASE_033] Turn the TAKATA MIDI I-SIZE
so that it faces the direction of travel, and place it
above the middle of the TAKATA I-SIZE BASE. Press
the two connection bolts in the seat area of the
TAKATA MIDI I-SIZE into the rear connection hooks
of the TAKATA I-SIZE BASE. For guidance, use the
arrows on the outside of the seat and on the rear
connection arms of the TAKATA I-SIZE BASE. The
bolts are properly locked into the rear connection
hooks when each one clicks into place, and you can
see a green marking on the top of each hook's release
element.
[I-SIZE_BASE_034] To secure the connection rod in
the foot area of the TAKATA MIDI I-SIZE with the
front connection hooks of the TAKATA I-SIZE BASE,
press down from above on the seat section of the
TAKATA MIDI I-SIZE, until you hear a click.
WARNING!
[I-SIZE_BASE_024] Do not use the TAKATA MIDI
I-SIZE if it is not correctly secured to the TAKATA
I-SIZE BASE. It is properly locked in place when you
can see a green marking on the top of each rear hook's
release element and if you checked prior to installation
of the TAKATA MIDI I-SIZE on the TAKATA I-SIZE
BASE that the rear connection hooks were open.
NOTE!
[I-SIZE_BASE_031] Check the TAKATA MIDI
I-SIZE is correctly secured to the TAKATA I-SIZE
BASE, by gently shaking the seat in each direction. If
the seat is not properly secured to the base, repeat Step
2 – Lock the seat into the TAKATA I-SIZE BASE
until it is in the correct position.
Removing the TAKATA MINI I-SIZE or TAKATA
MIDI I-SIZE from the TAKATA I-SIZE BASE
Step 1 – Release the rear connection hooks
[I-SIZE_BASE_024 + I-SIZE_BASE_035_1] The rear
hooks unlock together, so you only need to push down
one of the release elements on the TAKATA I-SIZE
BASE rear connection arms. At the same time, tilt the
TAKATA MINI I-SIZE or the TAKATA MIDI I-SIZE
forward (in the direction of travel), so that the
connection bolts of the seat come out of the rear
connection hooks of the TAKATA I-SIZE BASE.
Step 2 – Free the seat from the front connection hooks
and remove
[I-SIZE_BASE_035_2] Free the connection rod of the
TAKATA MINI I-SIZE or the TAKATA MIDI I-SIZE
from the front hooks of the TAKATA I-SIZE BASE by
sliding the TAKATA MINI I-SIZE or the TAKATA
MIDI I-SIZE backward, against the direction of travel.
You should now be able to lift the TAKATA MINI
I-SIZE or the TAKATA MIDI I-SIZE from the
TAKATA I-SIZE BASE, and remove it from your
vehicle.
Removing the TAKATA I-SIZE BASE
Step 1 – Unlock the ISOFIX connectors
[I-SIZE_BASE_014] Separate the connectors on the
TAKATA I-SIZE BASE from the ISOFIX points in the
vehicle, by moving the locking sliders of the release
sliders down and, at the same time, pulling the release
slider on each connector forward (in the direction of
travel). The components have been separated if a red
marking can be seen on the top of each ISOFIX
connector.
Step 2 – Retract the ISOFIX connectors
[I-SIZE_BASE_012] Press the left-hand button on the
ISOFIX length adjuster as far in as possible. The
button is positioned on the inner side of the TAKATA
I-SIZE BASE. At the same time, push the left-hand
connector back into the TAKATA I-SIZE BASE.
The two ISOFIX connectors must be adjusted
