3. - OPERATING INSTRUCTIONS

3.1. General information

CAUTION: DO NOT USE THIS HEATER TO DRY CLOTHES. Do not cover this heater at any time.
CONNECTION / DISCONNECTION
Power switch. All models are equipped with a switch on the back
side panel. It is used to connect and disconnect ECOMBI PLUS.
KEYBOARD:
Daily Programming:
Temperature level for each
time interval (1h) of the day.
Current charge level
Button "+"
Press the key to increase
different values.
ON/OFF
Once the heater is connected to a main supply you can turn the heater ON by switching the main ON/OFF switch positioned at
the rear right side of the heater as shown above.
BACKLIGHT
Pressing any button, the display will illuminate with a soft white colour. After certain time if no buttons are pressed the display
backlight will turn off.
Buttons only will respond when the backlight is on.

KEYBOARD LOCK

G-Control Hub
connection indicator.
Button "-" "OK" Button
Press the key to decrease
Press the button to check and
different values. set the time.
Press the button to confirm
values in the different menus.
During any operation mode, it is possible to lock the keyboard by holding
and simultaneously for 3 seconds. When the keyboard is locked, the
indicator will be displayed.
To unlock the keyboard, press
20
Current set point in
Programme Mode
Programme mode indicator
Key lock indicator
Open Windows detection
indicator
"Config / Prog" Button
Keep pressed the button to access
the advanced configuration.
Press this button to exit from the
different menus.
and simultaneously for 3 seconds.
