EDM 32507 Instrucciones Importantes De Seguridad página 7

32507
REF.
INSTRUÇÕES IMPORTANTES DE SEGURANÇA / IMPORTANT SAFETY INSTRUCTIONS
TEST
- Turn the TIME knob anti-clockwise on the minimum. Turn the LUX knob clockwise on the maximum (sun).
- Switch on the power; the lamp will have no signal at the beginning. After Warm-up 30sec, the lamp can start work .If it
receives the induction signal, the lamp will turn on. While there is no another induction signal any more, the lamp should
stop working within 10sec±3sec.
- Turn LUX knob anti-clockwise on the minimum (moon). If the ambient light is more than 3LUX, the lamp should not
work. If the ambient light is less than 3LUX (darkness), the sensor would work. Under no induction signal condition, the
lamp should stop working within 10sec±3sec.
Note: when testing in daylight, please turn LUX knob to
NOTE
- Should be installed by electrician or experienced person;
- Avoid installing it on the uneven object;
- There should be no hindrance and moving objects in front of the detection windows to affect detection;
- Avoid installing it near air temperature alteration zones such as air condition, central heating, etc;
- Considering your safety, please do not open the cover when you find the hitch after installation.
- If there is difference between instruction and the function the product has, please give priority to product and sorry not
to inform you additionally.
Good sensitivity
SOME PROBLEM AND SOLVED WAY
- The load does not work:
a. Please check if the connection of power source and load is correct.
b. Please check if the load is good.
c. Please check if the settings of working light correspond to ambient light.
- The sensitivity is poor:
a. Please check if there is any hindrance in front of the detector to affect it to receive the signals.
b. Please check if the ambient temperature is too high.
c. Please check if the induction signal source is in the detection field.
d. Please check if the installation height corresponds to the height required in the instruction.
e. Please check if the moving orientation is correct.
- The sensor can not shut off the load automatically:
a. Please check if there is continual signal in the detection field.
b. Please check if the time delay is set to the maximum position
c. Please check if the power corresponds to the instruction.
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
(SUN) position, otherwise the sensor lamp could not work!
-7-
Poor sensitivity
