Manual de instalación, operación y mantenimiento de PZM IntelliROL®
1.16: P
LATAFORMAS DE EMPUJE A LA IZQUIERDA Y A LA DERECHA DE LA
PLATAFORMA DE ALA
IBE-03 Inputs - Electric Lifts
Device Tag Card # Terminal #
I00PE 4 IN 3
I01PE 3 SEN B
I02PE 4 SEN B
I03LS 5 ALM B
I04PE 5 SEN B
I05PE 3 SEN A
I06PE 5 SEN A
I07PE 5 IN 3
I08PE 3 IN 1
I09PE 3 IN 2
I10PE 3 IN 3
I11PE 4 SEN A
I12PE 6 SEN A
I13PE 6 ALM B
I14PE 6 SEN B
I15PE 3 ALM B
I16PX 5 IN 1
I17PX 5 IN 2
I18PX 4 IN 1
I19PX 4 IN 2
I20PX 6 IN 1
I21PX 6 IN 2
3 ALM A
4 ALM A
4 ALM B
5 ALM A
6 IN 3
6 ALM A
Device Tag Card # Terminal #
O00M 3 OUT 2
O01M 3 OUT 3
O02M 4 MTR A
O03M 3 MTR A&B Run Transfer Belts
O04M 6 OUT 2
O05M 5 OUT 1
O06M 5 MTR A
O07M 3 OUT 4
O08M 3 OUT 5
O11M 5 OUT 2
O13M 6 OUT 1
O14M 6 MTR A
O16M 6 OUT 3
O17M 6 OUT 4
3 OUT 1
4 OUT 1
4 OUT 2
4 OUT 3
4 OUT 4
4 OUT 5
4 MTR B
5 OUT 3
5 OUT 4
5 OUT 5
5 MTR B
6 OUT 5
6 MTR B
P/N: 1220631
1234 (IB-E)
Description
Product Present Upstream of Transfer
Product Present Entering Transfer
Product Present Exiting Transfer Straight
Downstream Gate Closed
Downstream Conveyor Full
Product Present Entering Wing Bed 1 (LH)
Product Present On Wing Bed 1 (LH)
Product Present On Push Bed 1 (LH Upstream) Field
Product Present Entering Induct
Product Present At Gap Monitor
Product Present On Push Bed 2 (LH Downstream Field
Product Present Entering Wing Bed 2 (RH)
Product Present On Wing Bed 2 (RH)
Product Present On Push Bed 3 (RH Upstream) Field
Product Present On Push Bed 4 (RH Downstrea Field
Product Present On Transfer (Optional)
Transfer Raised
Transfer Lowered
Wing Bed 1 (LH) Lowered
Wing Bed 1 (LH) Raised
Wing Bed 2 (RH) Lowered
Wing Bed 2 (RH) Raised
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
IBE-03 Outputs
Description
Run Upstream Induct Stage 2
Run Downstream
Run Transfer Rollers
Raise/Lower Transfer
Raise/Lower Wing Bed 1 (LH)
Run Wing Bed 1 (LH)
Run Push Bed 1 (LH Upstream)
Run Upstream Induct Stage 1
Run Push Bed 2 (LH Downstream)
Raise/Lower Wing Bed 2 (RH)
Run Wing Bed 2 (RH)
Run Push Bed 3 (RH Upstream)
Run Push Bed 4 (RH Downstream)
OPEN (TERMINAL STRIP 11)
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
Fecha de revisión: 16/04/2021
Wired At:
Field
Bench
Bench
Field
Field
Bench
Bench
Field
Field
Bench
Bench
Bench
Bench
Bench
Bench
Bench
Bench
Bench
Wired At:
Field
Field
Bench
Bench
Bench
Bench
Bench
Field
Field
Field
Bench
Bench
Field
Field
09/25/2017
