After use, open the two parts, wash with soap and hot water and rinse it carefully. Remove excess of water with a soft, clean and dry cloth and leave to dry
naturally in a clean place. To sterilize, cover the medication container with a cold sterilizing solution, following the instructions on the sterilizer pack. It is rec-
ommended to use one personal medication container for each patient, to be use for 6 months or 120 treatments. Do not use boiling water to clean it. Carefully
wash mask and hoses with disinfectant solution only.
CONTAMINATION BY MICROBES
In case of pathologies of microbial or viral origin, where infection is possible, the device and its accessories should not be shared with other patients.

Troubleshooting

PROBLEM
The device is not turning on.
The device is turned on but it's not nebulizing.
NOTE: If the device shall not take again his correct functioning in spite of inspections effected, contact the ТМ Dr. Frei
Piston rotary presser, without lubrification. Medical device of class IIA according to Directive 93/42/EEC. Medicine Cup Adjustable.
Particles dimension: 3÷6 μm with regulation MMAD (EN13544-1); Product description: Nebulizer with adjustable medicine cup; Nebulization rate, ml/min:
From 0,2 to 0,4 ml/min; Compressor air flow (max): 15 ± 2 l/min; Medication capacity: 2 - 12 ml; Residual volume, ml: 0,85 ± 0,2 ml; Sound noise level:
Low noise (around 55 Db); Operating cycles: 30 min - ON/30 min - OFF; Accessories: Air tube (1,0 m), adult mask, child mask, mouthpiece, nosepiece,
air filters (5 pcs.) Nasal washer: Optional; Power source: 220V/50Hz; Power lead length: 1,4 m; Weight: 1,3 kg; Dimensions: 167*106*164 mm; Power:
120 VA;
Operating conditions:
Ambient temperature: min 5°C - max 40°C; Air humidity: min 15% RH - max 93% RH;
Atmospheric pressure: min 700hPa - max 1060hPa (max operating altitude ≤ 2000 m).
Storage conditions:
Ambient temperature: min -25°C/max +70°C; Air humidity: min 0%RH - max 93%RH; Atmospheric pressure: min 500 hPa - max 1060 hPa.
* Subject to technical modification without prior notice.
This device has an expected service life of about 2.000 therapy cycles, basing on an average therapy duration of 8 min.
Electromedical devices require special care. During installation and use with respect to EMC requirements, it therefore required that they are installed and/or used ac-
cording to the manufacturer's specification. Potential risk of electromagnetic interference with other devices, in particular with other devices for analysis and treatment.
Radio and mobile telecommunications devices or portable RF (mobile phones or wireless connections) may interfere with the operation of electromedical device.
SYMBOL
Alternate current
Double insulation
BF applied part
Obligation to read instruction manual
General warning symbol
Protection against solid and liquid bodies penetra-
tion (protected against solid bodies over 12 mm;
IP 21
protected against access with a finger; protected
against vertically falling water drops).
This product (including its related accessories) must be delivered at the end of its service life at a collection point for
the recycling by electric and electronic devices, by the user or by His dealer.
6

TECHNICAL SPECIFICATIONS

REFERENT
ACTION
• Make sure the plug has been correctly inserted in the main supply.
• Make sure switch is on the position turned on (I).
• Make sure to have inserted the pisper into the medicine cup (8).
• Make sure the air connection pipe is not bended or crushed (9).
• Make sure air suction filter is not stopped or dirty. In that case replace
it with a new one (10).
• Make sure the medicine cup has been filled in with medicine.

SYMBOL DESCRIPTION

SYMBOL
Medical CE mark ref. Dir 93/42 EEC
Do not use the appliance when taking a bath
or shower
I/ON
Switch ON
O/OFF
Switch OFF
Read instruction manual
Keep dry
service center in your country.
®
