Daikin RYYQ-T Datos Técnicos página 255

5 Tablas de capacidad
5 - 8 Tablas de capacidades de calefacción
RYYQ48T
Outdoor
Combination(%)
air temp.
(Capacity index)
(°CDB) (°CWB)
-19.8 -20.0
-18.8 -19.0
-16.7 -17.0
-13.7 -15.0
-11.8 -13.0
-9.8 -11.0
-9.5 -10.0
-8.5 -9.1
-7.0 -7.6
90% -5.0 -5.6
-3.0 -3.7
0.0 -0.7
3.0 2.2
5.0 4.1
7.0 6.0
9.0 7.9
11.0 9.8
13.0 11.8
15.0 13.7
-19.8 -20.0
-18.8 -19.0
-16.7 -17.0
-13.7 -15.0
-11.8 -13.0
-9.8 -11.0
-9.5 -10.0
-8.5 -9.1
-7.0 -7.6
80% -5.0 -5.6
-3.0 -3.7
0.0 -0.7
3.0 2.2
5.0 4.1
7.0 6.0
9.0 7.9
11.0 9.8
13.0 11.8
15.0 13.7
-19.8 -20.0
-18.8 -19.0
-16.7 -17.0
-13.7 -15.0
-11.8 -13.0
-9.8 -11.0
-9.5 -10.0
-8.5 -9.1
-7.0 -7.6
70% -5.0 -5.6
-3.0 -3.7
0.0 -0.7
3.0 2.2
5.0 4.1
7.0 6.0
9.0 7.9
11.0 9.8
13.0 11.8
15.0 13.7
-19.8 -20.0
-18.8 -19.0
-16.7 -17.0
-13.7 -15.0
-11.8 -13.0
-9.8 -11.0
-9.5 -10.0
-8.5 -9.1
-7.0 -7.6
60% -5.0 -5.6
-3.0 -3.7
0.0 -0.7
3.0 2.2
5.0 4.1
7.0 6.0
9.0 7.9
11.0 9.8
13.0 11.8
15.0 13.7
-19.8 -20.0
-18.8 -19.0
-16.7 -17.0
-13.7 -15.0
-11.8 -13.0
-9.8 -11.0
-9.5 -10.0
-8.5 -9.1
-7.0 -7.6
50% -5.0 -5.6
-3.0 -3.7
0.0 -0.7
3.0 2.2
5.0 4.1
7.0 6.0
9.0 7.9
11.0 9.8
13.0 11.8
15.0 13.7
• Unidad exterior • Bomba de calor VRV IV • RYYQ-T
Indoor air temp. °CDB
16.0 18.0
TC PI TC PI
KW KW KW KW
86.3 30.1 86.0 31.7
87.8 30.5 87.5 32.1
91.2 31.5 90.9 33.0
95.0 32.4 94.8 33.9
99.2 33.4 99.0 34.8
104 34.3 104 35.7
106 34.8 106 36.1
109 35.2 108 36.5
113 35.9 112 37.2
118 36.9 118 38.0
124 37.7 124 38.8
134 39.0 134 40.0
144 40.1 144 41.0
151 40.8 145 39.3
156 40.2 145 37.0
156 37.8 145 34.9
156 35.7 145 32.9
156 33.6 145 31.0
156 31.8 145 29.4
85.8 32.7 85.5 34.2
87.3 33.1 87.1 34.5
90.8 34.0 90.5 35.3
94.6 34.8 94.3 36.1
98.8 35.7 98.5 36.9
103 36.5 103 37.7
106 37.0 106 38.1
108 37.3 108 38.5
112 38.0 112 39.0
118 38.8 118 39.8
124 39.5 123 40.5
133 40.6 129 39.7
138 39.3 129 36.2
138 37.0 129 34.2
138 34.9 129 32.2
138 33.0 129 30.5
138 31.1 129 28.8
138 29.4 129 27.2
138 27.8 129 25.8
85.3 35.4 85.1 36.6
86.9 35.7 86.7 37.0
90.3 36.5 90.1 37.6
94.1 37.2 93.9 38.3
98.3 38.0 98.1 39.0
103 38.7 103 39.7
105 39.1 105 40.1
108 39.4 107 40.4
112 40.0 111 40.9
117 40.7 113 39.4
121 40.4 113 37.2
121 36.7 113 33.9
121 33.6 113 31.0
121 31.7 113 29.3
121 29.9 113 27.7
121 28.3 113 26.2
121 26.8 113 24.9
121 25.3 113 23.5
121 24.0 113 22.3
84.8 38.1 84.7 39.1
86.4 38.4 86.2 39.4
89.8 39.0 89.6 40.0
93.6 39.6 93.4 40.6
97.8 40.3 96.9 40.7
102 40.9 96.9 38.5
104 40.6 96.9 37.4
104 39.5 96.9 36.4
104 37.8 96.9 34.8
104 35.6 96.9 32.8
104 33.6 96.9 31.1
104 30.7 96.9 28.4
104 28.2 96.9 26.1
104 26.7 96.9 24.7
104 25.2 96.9 23.4
104 23.9 96.9 22.2
104 22.7 96.9 21.1
104 21.5 96.9 20.0
104 20.4 96.9 19.0
84.4 40.7 80.8 39.0
85.9 41.0 80.8 38.1
86.5 39.5 80.8 36.4
86.5 37.5 80.8 34.6
86.5 35.6 80.8 32.8
86.5 33.7 80.8 31.1
86.5 32.7 80.8 30.2
86.5 31.9 80.8 29.5
86.5 30.6 80.8 28.3
86.5 28.9 80.8 26.7
86.5 27.3 80.8 25.3
86.5 25.1 80.8 23.3
86.5 23.1 80.8 21.5
86.5 21.9 80.8 20.4
86.5 20.8 80.8 19.4
86.5 19.8 80.8 18.4
86.5 18.8 80.8 17.6
86.5 17.9 80.8 16.7
86.5 17.0 80.8 15.9
• VRV Systems • Unidad exterior
TC: Total capacity (kW); PI: Power Input (kW) (Comp. + Outdoor fan motor)
