Parameterization
Input in Motor order
P097 number
(MPRD)
30 1PH7186-2_L
31 1PH7224-2_B
32 1PH7224-2_D
33 1PH7224-2_U
34 1PH7224-2_L
35 1PH7226-2_B
36 1PH7226-2_D
37 1PH7226-2_F
38 1PH7226-2_L
39 1PH7228-2_B
40 1PH7228-2_D
41 1PH7228-2_F
42 1PH7228-2_L
43 1PL6184-4_B
44 1PL6184-4_D
45 1PL6184-4_F
46 1PL6184-4_L
47 1PL6186-4_B
48 1PL6186-4_D
49 1PL6186-4_F
50 1PL6186-4_L
51 1PL6224-4_B
52 1PL6224-4_D
53 1PL6224-4_F
54 1PL6224-4_L
55 1PL6226-4_B
56 1PL6226-4_D
57 1PL6226-4_F
58 1PL6226-4_L
59 1PL6228-4_B
60 1PL6228-4_D
61 1PL6228-4_F
62 1PL6228-4_L
63 1PH4103-4_F
64 1PH4105-4_F
65 1PH4107-4_F
66 1PH4133-4_F
8-50
Rated Pole pair Current
speed number
n [rpm] Z
n p
2900 2
400 2
1150 2
1750 2
2900 2
400 2
1150 2
1750 2
2900 2
400 2
1150 2
1750 2
2900 2
400 2
1150 2
1750 2
2900 2
400 2
1150 2
1750 2
2900 2
400 2
1150 2
1750 2
2900 2
400 2
1150 2
1750 2
2900 2
400 2
1150 2
1750 2
2900 2
1500 2
1500 2
1500 2
1500 2
Operating Instructions
Voltage
I [A] U [V]
n n
206.0 385
88.0 268
160.0 385
203.0 395
274.0 395
114.0 264
197.0 390
254.0 395
348.0 390
136.0 272
238.0 390
342.0 395
402.0 395
69.0 300
121.0 400
166.0 400
209.0 400
90.0 290
158.0 400
231.0 400
280.0 390
117.0 300
218.0 400
292.0 400
365.0 400
145.0 305
275.0 400
350.0 400
470.0 400
181.0 305
334.0 400
470.0 400
530.0 400
20.2 350
27.3 350
34.9 350
34.1 350
6SE7087-8JK50
SIMOVERT MASTERDRIVES
10.2006
Torque Frequency
M [Nm] f [Hz]
n n
333 97.3
725 14.0
670 38.9
600 58.9
490 97.3
935 14.0
870 38.9
737 58.9
610 97.2
1145 13.9
1070 38.9
975 58.8
708 97.2
585 14.4
540 39.4
486 59.3
372 97.6
752 14.3
706 39.4
682 59.3
494 97.5
1074 14.2
997 39.1
900 59.2
675 97.5
1361 14.0
1287 39.2
1091 59.1
889 97.4
1719 14.0
1578 39.2
1446 59.0
988 97.3
48 52.9
70 53.1
89 52.8
95 51.9
