NOTE: By default the TCP/IP settings should already be defined.
5. Click Save to save the changes.
6. Select Connection. The Connection Parameters page is displayed.
Figure 20 Connection Parameters
7. Set the following port connection parameters of the camera:
TCP Port
UDP Port
HTTP Port
RTSP Port:
HTTPS Port
8. Click Save to save the changes.
9. Repeat the above steps for each camera using the relevant IP address and
alternative port number for each.
Step 3: Router Port Forwarding Settings
By default, the security features on many routers prevent access to the devices on
your home/business network from the Internet. To open a port, you need to
enable "port forwarding" on your router. Router administration screens can
vary, but typically, you would do the following to open a port:
1. Return to the Router Interface page.
NOTE: For more information on how to navigate your specific router please
check the routers User manual.
Set the TCP port you want to define for the camera (in our
example 47777).
Set the UDP port (in our example 47778)
The default port number is 80, and can be changed to any
port range 1024 to 65535 (in our example 10080).
The default port number is 554 (in our example 47554).
The default port number is 443, and can be changed to any
port range 1024 to 65535 (in our example 47443).
