3.5 Address assignment of the valve solenoid coils

Each valve location occupies 2 addresses.
The following applies:
solenoid coil 14 occupies the lower−value address,
solenoid coil 12 occupies the higher−value address.
Addresses are assigned to the valve solenoid coils in
ascending order without gaps, from left to right.
Examples for combinations of the electric MPM linking
Outputs
MPA2: 2 coils
MPA2: 2x2 coils
MPA1: 4 coils
MPA2: 4 coils
MPA1: 4 coils
1)
Mix single−solenoid and double−solenoid valves
Festo VMPA−ASI−EPL−...−4E4A−Z 0705NH English
1)
+ 4 x zero
1 2
...−EV−AB−2
...−EV−AB−2
...−EV−AB−4
...−EV−AB−4
...−EV−AB−8
3 4
...−EV−AB−2
