Always t urn ONyourhood before y oubegin cooking i norder
toestablish anairflowinthekitchen. Lettheblower runfora
fewminutes toclear t heairafter y outurnofftherange. This
willhelp keep thewhole kitchen c leaner andbrighter.
0
_
_
0
_,0
HT_S
©
[©Qq>@l
@
F¢
1
2
3
4
5
1. Blower Delay switch
4. Filter maintenance indicator
2. ON/OFF Blower speed switches
5. Nightlight switch
3. Halogen lights switch
Delay OFF switch
When a speed is selected, press the Delay OFF switch to
activate the delay function. The corresponding speed indicator
LED will start flashing to indicate this function is activated.
The fan will continue to operate for 5 minutes and will stop
automatically. To cancel the delay function, press the Delay
OFF switch once again; the blower will then work in normal
mode.
NOTE: The blower speed can be increased - or decreased -
during Delay mode without starting another 5-minute cycle.
ON/OFF Slower speed switches
Press the switch corresponding
to the desired blower speed.
The light over the switch indicates the selected speed (from 1
for low speed to 4 for high speed). To turn off the blower, press
once more on the corresponding
blower speed switch.
HEAT SENTRY
Your hood is equipped with a HEAT SENTRY thermostat. This
thermostat is a device that will turn on or speed up the blower
if it senses excessive heat above the cooking surface. The
light indicator over speed 3 switch will quickly flash.
1) If blower is OFF - it turns blower ON to speed 3.
2) If blower is ON at a lower (or higher) speed setting - it turns
blower to speed 3.
When the temperature
level drops to normal, the blower will
return to its original setting and the light indicator over speed
3 switch will stop flashing.
WARNING:The
HEAT SENTRY thermostat
can
start the blower even if the hood is turned OFE
When this occurs, press the speed 3 switch
until its light indicator stops flashing if you must
stop the blower.
Halogen lights switch
This switch provides 3 different lighting levels, according to
your needs. The lighting intensity changes by increments of 1
(e.g.: press once for low intensity, once again to get more, up
to three times). From the higher intensity, press once again to
shut off the lights.
Use 120 Volts, 50 W, MR 16 with GU10 base or PAR 16 with
GU10 base, shielded halogen bulbs (included).
_
WARNING:
in order to prevent the risk of
personal injury, do not install a lamp identified
for use only in enclosed
fixtures.
Filter maintenance
indicator
After 24 hours of operation, the filter maintenance light indicator
will start blinking. This indicates the filters need to be cleaned
in order to maintain efficient operation of the unit. The indicator
light will blink until the function is reset by pressing the nightlight
switch for 3 seconds.
Nigthlight
switch
Press this switch once to turn on the nightlight.
Press this
switch once more to shut off the nightlight.
Grease filters
The grease filters and the bottom panel should be cleaned
frequently. Use a warm detergent solution. Grease filters are
dishwasher
safe.
Wash more often if your cooking
style generates
greater
grease - like frying foods or wok cooking.
Remove filters by pulling latch tabs and rotating filters downward.
Hood Cleaning
Stainless steel cleaninq_ How to maintain its "BRIGHT LOOK"
Do:
Regularly wash surfaces with clean cloth or rag soaked
with warm water and mild soap or liquid dish detergent.
Always clean in the direction of original polish lines.
Always rinse well with clear water (2 or 3 times) after cleaning.
Wipe dry completely.
You may also use a specialized household stainless steel
cleaner.
Don't:
Do not use any steel or stainless steel wool or any other
scrapers to remove stubborn dirt.
Do not use any harsh or abrasive cleaners.
Do not allow dirt to accumulate.
Do not let plaster dust or any other construction
residues
reach the hood. During construction/renovation,
cover the
hood to make sure no dust sticks to stainless steel surface.
Avoid: when choosing
a detergent
Any cleaners that contains bleach will attack stainless steel.
Any products containing: chloride, fluoride, iodide, bromide
will deteriorate
surfaces rapidly.
Any combustible
products
used for cleaning
such as
acetone, alcohol,
ether, benzol, etc., are highly explosive
and should not be used close to a range.
Enamel Finish:
Clean with warm water and mild detergent only. If discoloration
occurs, use a good enamel polish such as automotive polish.
(DO NOT use rough abrasive cleaner or porcelain cleaner).
3
