Sutron XLINK100 Guia De Inicio Rapido página 6

7. Select the data format and destination server
Go to the "Telemetry" tab in
LinkComm
Select "Enable" to turn on TX1, and
select radio type as "Cell," kind as
"scheduled" and the label is optional
Set scheduled time and interval as
"00:00:30" and "01:00:00"
respectively
Select Tx format as "MIS" and date
format as "YYYYMMDD"
Setup "scheduled" transmissions as
shown on the right
Setup "Alarm" transmissions
The setup is now ready to be sent to
XLINK100/500; Click the "Changed"
icon and transfer the setup;
8. Send Setup to the unit and start recording
Following step # 7.7, recording can be turned on the unit, by toggling the "Stop" symbol
This completes the setup of the unit.
9. Get More Information
Download the user manual from
Watch YouTube Videos on Sutron Channel
Contact Sutron customer service – service@sutron.com
http://www.sutron.com/downloads.htm
EN-4
7.7
7.2
7.3
7.4
7.5
7.1
7.6
8800-1218 Rev C.
