2. PRODUCT DESCRIPTION

All the pictures in this manual are for explanation
purposes only. The actual shape of the indoor unit
you purchased may be slight different on front
panel and display window. The actual shape shall
prevail.
2.1 Split Type
12
1 Front panel
2 Air inlet
3
Air filter
4 Air outlet
5 Horizontal air flow grille
6 Vertical air flow louver(inside)
2
4
11
SET TEMPERATURE( C)
AUTO FAN
COOL HIGH
DRY MED
HEAT LOW
TEMP
ON/OFF
MODE FAN SPEED
SWING ECONOMY TIMER ON
ION TIMER OFF
RESET LOCK
FOLLOW
LED
ME TURBO
DISPLAY
1 3
Air inlet
Air Outlet
5 6
Air inlet (side)
Air outlet
7 Display panel
8 Connecting pipe (optional)
9
Connecting cable (optional)
10 Stop Valve
11 Remote controller
12 Mounting plate
7
Air inlet (rear)
