NAME AND SCHEMATIC OF EACH PART

1. Moving Blade
2. Fixed Blade
3. Pin
4. Trigger
1 3
2
8
7
5. Power Control Switch
6. Battery Pack Inserts
7. Charger Plug
8. Charger AC Socket
4
10
7
9. Battery Removal Button
10. Battery Charging Jack
11. Battery Discharge Socket
12. Oil hole
6
11
9
23
ALTUNA AB32
|
12
5
