Test Pass/OK Screen

When testing ISDN wiring, any resistive terminators
should be switched out of the circuit or disconnected.
Failure to do so could lead to erroneous test results.
• The left side of the display shows information about the test per-
formed and the status of the test result.
• The first line shows the unique identity of the active remote unit
connected to the far end (in this case, ID1). There are 15 addi-
tional active remote units available as optional accessories (ID#2
to ID#16).
• The test status, PASS is indicated on the second line. A test
PASS is confirmed by a double beep from the main unit and a
double green flash on the LED of the active remote unit.
• Next, information about the test type selected, along with a mea-
sured value of the cable length, and an indication of the current
VP setting is displayed.
• If a fault is found an appropriate message will be displayed, along
with a warning tone on the main unit, and a red flashing LED on
the remote unit.
14
ID1 4 5 1 2 3 6 7 8 S
PASS
TIA568
L=94ft
Vp=71%
4 5 1 2 3 6 7 8 S
Cable OK
Wire Mapper Pro Model CA7028
