Dimensiones (Mm) - Pce Instruments Kern Serie Manual De Instrucciones

1.1

Dimensiones (mm)

A
HFM 1T0.1 270
HFM 3T0.5 270
HFM 5T0.5 297
HFM 10T1 297
4
B C D
173 200 40
173 200 40
185 230 55
185 230 60
∅ 1
F H
98 285 51
95 540 63,5
95 635 63,5
110 750 76,2
∅ 2 ∅ 3
X
68 25 540
74 29 610
74 29 700
92 35 840
