ADJUST CLOSED POSITION

Unit not in full closed position.
a) Apply power to terminals 1 & 3 to move close cam knob counter-clockwise toward closed position. Do not
remove power.
b) With a 3/8 wrench, move close cam knob clockwise slightly and release, to jog motor, until motor moves the
drive shaft to the desired closed position. If necessary, repeat jogging movement until desired closed position is
attained. Use the flats on the drive shaft as a guide for position.
Unit past full closed position.
a) Apply power to terminals 1 & 2 to move actuator shaft to the open position. At this time move the close cam
knob to align the notch at the base of the cam knob, with the PC board attachment screw.
b) Reapply power to terminals 1 & 3.
c) With a 3/8 wrench, move close cam knob clockwise slightly and release, to jog motor, until the motor moves
the drive shaft to the desired closed position. If necessary, repeat jogging movement until the desired closed
position is attained.
