: The resistance of the test leads are not included in the test measurement
5.1.5. Displayed icons (symbols) and messages when using the RE functions.
: the test leads to the appropriate terminals indicated by color coding.
: Low Battery (The icon will be flashing along with the beep sound).
: The resistance of the test leads are included in the test measurement
: The resistance of the test leads are not included in the test measurement
5.1.6. Displayed icons(symbols) and messages in INSULATION function
: Low Battery (The icon will be flashing along with the beep sound).
: Indicates high voltage (125V, 250V,500Vor 1000V) at probe terminals, Use caution
5.2 USING THE LOOP / PFC FUNCTION, VOLTAGE AND RCD FUNCTION
1. Before you do a loop impedance test, use the zero adapter to zero the test leads or the mains cord. Press
and hold F3 button for more than two seconds until the
lead resistance, stores the reading in memory, and subtracts it from readings. The resistance value is saved
even when the power is turned off so it is unnecessary to repeat the operation each time you use the tester
with the same test leads or mains cord.
Note
Be sure the batteries are in good charge condition before you zero the test leads.
2. You can select UL Voltage by Pressing and hold F4 button for more than two seconds (25V or 50V).
5.2.1 Using the No Trip LOOP Measurement
The No Trip LOOP Measurement to be selected where the circuit is protected by an RCD whose rating is 30
mA or above.
19
Indicates correct input terminal connectivity. The user should connect
Indicates correct input terminal connectivity. The user should connect
: the test leads to the appropriate terminals indicated by color coding.
annunciator appears. The tester measures the
